Product Details:
|
| Features: | Easy To Operate, Durable, And With Long Life Span | Application: | SMT Magazine Type Unloader For L-size PCBs |
|---|---|---|---|
| Description: | Magazine Type PCB Loader Unloader L-Type | Brand: | INFITEK |
| Model: | UL-LL-TN | PCB Size: | 50*80-530*390 Mm |
| Warranty: | 1-Year | Reliability: | Industrial Grade Design |
| Packaging: | Wooden Crate | ||
| High Light: | PCB Magazine Unloader 900mm,530*390mm PCB Magazine Unloader,PCB Unloader |
||
Automatic Magazine Type PCB Unloader for LL-size PCBs - 50*80-530*390mm PCB Sizes | INFITEK Board Handling Equipment
SMT PCB Magazine Unloader with model number UL-LL-TN is a board handling equipment used in SMT Production Line. This Magazine Type PCB Unloading machine was designed by INFITEK using its own developed design and software and used quality and imported branded parts to ensure quality, durability, product efficiency, and operational safety level. The INFITEK UL-LL-TN Automatic PCB Unloading Machine is designed to be used for LL-size PCBs and has an adjustable rail width that can handle PCBs with sizes from 50*80-530*390mm.
SMT PCB Magazine Unloader
Model: UL-LL-TN
Applicable PCB Sizes: 50*80-530*390 (mm)
PCB Magazine Size: 535*460*563 (mm)
Machine Dimensions: 2260*909*1250 (mm)
Machine Weight: 280 kg.
Features:
| TECHNICAL PARAMETERS | |
| Description | This unit is used for unloading and of PCBs using a PCB Magazine |
| No. of magazine | Loader: upper 1, lower 2 / Unloader: upper 1, ,lower 1 |
| Time feed PCB | Seconds 6 Approx. or specify |
| Magazine replacement time indexing pitch | 10.20.30.40mm or specify |
| Power supply | AC1P110V/220V |
| Power | Max300VA |
| Air pressure | 4-6bar,10ltr/min max |
|
Transport height |
900±20mm (or customized) |
| Transport direction | From left to right or right to left |
Operation Diagram:
