Product Details:
|
| Features: | Easy To Operate, Durable, And With Long Life Span | Application: | SMT Magazine Type Unloader For XXL-size PCBs |
|---|---|---|---|
| Description: | Magazine Type PCB Loader Unloader XXL-Type | Brand: | INFITEK |
| Model: | UL-XXL-TN | PCB Size: | 50*80-530*460 Mm |
| Warranty: | 1-Year Warranty Period | Reliability: | Design For Industrial Use |
| Packaging: | Wooden Box Package | ||
| Highlight: | PCB Magazine Unloader 50*80mm,PCB Magazine Unloader 610*460mm,Automatic PCB Unloader |
||
Automatic Magazine Type PCB Unloader for XXL-size PCBs - 50*80-610*460mm PCB Sizes | INFITEK Board Handling Equipment
INFITEK UL-XXL-TN model PCB Magazine Unloader is the design intended by INFITEK for magazine type PCB unloading machine used to transfer PCBs in SMT Production Line. This board handling equipment is carefully and meticulously designed by expert Engineers to be quality, durable, and efficient. It has enough safety features to be safe to use in the SMT Production Line. The XXL-TN model is designed for use with XXL-size PCBs and is suitable for PCBs with sizes ranging from 50*80-610*460mm. The board handling equipment manufactured by INFITEK is equipped with original-branded parts and independently developed features and software that ensure durability to provide mechanical stability and great operation efficiency.
SMT PCB Magazine Unloader
Model: UL-XXL-TN
Applicable PCB Sizes: 50*80-610*460 (mm)
PCB Magazine Size: 630*530*563 (mm)
Machine Dimensions: 2610*1230*1250 (mm)
Machine Weight: 450 kg.
Features:
| TECHNICAL PARAMETERS | |
| Description | This unit is used for unloading and of PCBs using a PCB Magazine |
| No. of magazine | Loader: upper 1, lower 2 / Unloader: upper 1, ,lower 1 |
| Time feed PCB | Seconds 6 Approx. or specify |
| Magazine replacement time indexing pitch | 10.20.30.40mm or specify |
| Power supply | AC1P110V/220V |
| Power | Max300VA |
| Air pressure | 4-6bar,10ltr/min max |
|
Transport height |
900±20mm (or customized) |
| Transport direction | From left to right or right to left |
Operation Diagram:
