Product Details:
|
| Features: | Easy To Operate, Durable, And With Long Life Span | Application: | SMT Magazine Type Unloader For M-size PCBs |
|---|---|---|---|
| Description: | Magazine Type PCB Loader Unloader | Brand: | INFITEK |
| Model: | UL-M-TN | PCB Size: | 50*80-330*250 Mm |
| Warranty: | 1 Year | Reliability: | Industrial Use |
| Packaging: | Wooden Box | ||
| High Light: | AC 220V PCB Magazine Unloader,PCB Magazine Unloader 330*250mm |
||
Automatic Magazine Type PCB Unloader for M-size PCBs - 50*80-330*250mm PCB Sizes | INFITEK Board Handling Equipment
INFITEK UL-M-TN is a model of Magazine Type PCB unloader used in SMT Production Line. This board handling equipment uses a combination of independently developed design and branded parts. The INFITEK UL-M-TN Automatic PCB Unloader is designed with high quality, durability, and a long life span. The UL-M-TN Magazine Type PCB Unloader is designed for M-size PCBs and has an adjustable rail width adjustment that can accommodate PCBs with sizes from 50*80mm to 330*250mm.
SMT PCB Magazine Unloader
Model: UL-M-TN
Applicable PCB Sizes: 50*80-330*250 (mm)
PCB Magazine Size: 355*320*563 (mm)
Machine Dimensions: 1730*765*1250 (mm)
Machine Weight: 160 kg.
Features:
| TECHNICAL PARAMETERS | |
| Description | This unit is used for unloading and of PCBs using a PCB Magazine |
| No. of magazine | Loader: upper 1, lower 2 / Unloader: upper 1, ,lower 1 |
| Time feed PCB | Seconds 6 Approx. or specify |
| Magazine replacement time indexing pitch | 10.20.30.40mm or specify |
| Power supply | AC1P110V/220V |
| Power | Max300VA |
| Air pressure | 4-6bar,10ltr/min max |
| Transport height | 900±20mm (or customized) |
| Transport direction | From left to right or right to left |
Operation Diagram:
