Product Details:
|
| Features: | Easy To Operate, Durable, And With Long Life Span | Application: | SMT Magazine Type Unloader For L-size PCBs |
|---|---|---|---|
| Description: | Magazine Type PCB Loader Unloader L-Type | Brand: | INFITEK |
| Model: | UL-L-TN | PCB Size: | 50*80-445*330 Mm |
| Warranty: | 1 Year Warranty | Reliability: | Industrial Grade |
| Packaging: | Wooden Box / Crate | ||
| High Light: | PCB Magazine Unloader L-Size,PCB Magazine Unloader 445*330mm,SMT Unloader |
||
Automatic Magazine Type PCB Unloader for L-size PCBs - 50*80-445*330mm PCB Sizes | INFITEK Board Handling Equipment
INFITEK UL-L-TN Automatic Unloader is a type of Magazine Type PCB Unloader used in SMT Production Line. This board handling equipment was designed by INFITEK using ideas and designs and problems that were independently developed and combined with original and branded parts to produce a quality, high level of durability, reliable durability, and above all, ensured a high level of user safety. The UL-L-TN Automatic Magazine Type PCB Unloader is the model designed for use with L-size PCBs. It has an adjustable width that can accommodate PCBs with sizes from 50*80-445*330mm.
SMT PCB Magazine Unloader
Model: UL-L-TN
Applicable PCB Sizes: 50*80-445*330 (mm)
PCB Magazine Size: 460*400*563 (mm)
Machine Dimensions: 2065*845*1250 (mm)
Machine Weight: 220 kg.
Features:
| TECHNICAL PARAMETERS | |
| Description | This unit is used for unloading and of PCBs using a PCB Magazine |
| No. of magazine | Loader: upper 1, lower 2 / Unloader: upper 1, ,lower 1 |
| Time feed PCB | Seconds 6 Approx. or specify |
| Magazine replacement time indexing pitch | 10.20.30.40mm or specify |
| Power supply | AC1P110V/220V |
| Power | Max300VA |
| Air pressure | 4-6bar,10ltr/min max |
| Transport height | 900±20mm (or customized) |
| Transport direction | From left to right or right to left |
Operation Diagram:
